Amperage (amps) measures how much electrical current flows through a wire. Think of it like water pressure in a pipe - voltage pushes the current, and amps measure how much is actually flowing. For sauna owners, amperage matters because it determines the size of your circuit breaker, the gauge of your wiring, and whether your electrical panel can handle the load.
How Much Amperage Do Saunas Use?
- 120V infrared saunas: 15-20 amps (plugs into a standard outlet, but needs a dedicated circuit)
- 240V infrared saunas: 20-30 amps
- 240V traditional heaters (small, 4.5-6kW): 20-30 amps
- 240V traditional heaters (mid, 6-9kW): 30-50 amps
- 240V traditional heaters (large, 9-12kW): 40-60 amps
Shop all saunas at SweatDecks
- FD-1 Full-Spectrum Infrared Sauna - $4,695
- FD-3 Full Spectrum Infrared Sauna - $6,495
Affirm financing available. Free curbside shipping on orders over $5,000. See all all saunas.
Amps, Volts, and Watts Explained
These three terms are directly related:
- Volts (V): The "pressure" pushing electricity. US residential power comes in 120V (standard outlets) and 240V (heavy appliance circuits).
- Watts (W): Total power consumption. What you pay for on your electric bill. A 6,000-watt heater uses 6kW.
- Amps (A): Amount of current flowing. Amps = Watts / Volts. This determines your wire and breaker size.
A 6,000-watt heater on 240V draws 25 amps. That same heater on 120V would draw 50 amps - which is why larger heaters require 240V circuits. The higher voltage keeps amperage manageable.
Why Getting Amps Right Matters
If your wiring and breaker aren't sized for the amps your sauna draws, an undersized circuit trips the breaker every time the heater kicks in. Worse, undersized wiring can overheat and become a fire hazard before the breaker trips. Oversizing is fine from a safety standpoint - just costs a bit more for heavier wire.
The Quick Math
Divide wattage by voltage. A 6,000-watt heater on 240V = 25 amps. Your breaker needs 125% of that continuous load, so at least a 30-amp breaker and matching wire. Every sauna lists its amp draw in the specs. Match those numbers or hand the spec sheet to your electrician.
Wire Gauge and Amperage
Wire gauge must match your amperage. Too-thin wire creates resistance and generates heat in the wire itself:
- 15 amps: 14-gauge wire
- 20 amps: 12-gauge wire
- 30 amps: 10-gauge wire
- 40 amps: 8-gauge wire
- 50 amps: 6-gauge wire
- 60 amps: 4-gauge wire
Lower gauge numbers mean thicker wire. For runs over 50 feet from panel to sauna, go up one wire size to compensate for voltage drop.
Checking Your Panel Capacity
Most residential panels are 100 or 200 amps. Adding a 50-amp sauna circuit to a 100-amp panel already running AC, water heater, and dryer could push you over capacity. Have your electrician do a load calculation first. You may need a panel upgrade, which adds cost but is non-negotiable for safety.
120V vs. 240V: What It Means for You
Most small infrared saunas run on 120V - plug into a standard outlet on a dedicated circuit. No electrician needed. But 120V limits you to about 1,500 watts (12.5 amps), enough for only 1-2 person infrared units.
Anything larger needs 240V. Traditional heaters, larger infrared cabins, and any heater over 1,800 watts require hardwired 240V installation. Wiring costs range from a few hundred to over a thousand dollars depending on panel distance and local labor rates.
